| Model： | Master plus 160 | Master plus 120T | Master plus 160T | ||
| Heating Capacity Range | kW | 4-18 | 3-13 | 4-18 | |
| Heating (A7/6℃,W30/35℃) | Heating Capacity | kW | 16.2 | 12.1 | 16.2 |
| Power Input | kW | 3.58 | 2.66 | 3.56 | |
| Current | A | 15.26 | 4.41 | 5.89 | |
| COP | W/W | 4.52 | 4.55 | 4.55 | |
| Heating (A7/6℃,W40/45℃) | Heating Capacity | kW | 16.03 | 12.03 | 16.03 |
| Power Input | kW | 5.02 | 3.30 | 4.98 | |
| COP | W/W | 3.19 | 3.65 | 3.22 | |
| Heating (A7/6℃,W47/55℃) | Heating Capacity | kW | 16.10 | 12.10 | 16.10 |
| Power Input | kW | 5.56 | 4.05 | 5.43 | |
| COP | W/W | 2.90 | 2.99 | 2.97 | |
| Cooling (A35/24℃,W23/18℃) | Cooling Capacity | kW | 15.10 | 11.30 | 15.20 |
| Power Input | kW | 3.96 | 2.91 | 3.98 | |
| EER | W/W | 3.81 | 3.88 | 3.82 | |
| Cooling (A35/24℃,W12/7℃) | Cooling Capacity | kW | 15.05 | 10.60 | 15.75 |
| Power Input | kW | 5.26 | 3.58 | 5.56 | |
| EER | W/W | 2.86 | 2.96 | 2.83 | |
| Rated water flow | m3/h | 2.8 | 2.1 | 2.8 | |
| Rated voltage /Frequency | V/Hz | 220~240/50 | 380~415/50 | 380~415/50 | |
| Maximum input power | kW | 6.60 | 4.70 | 6.50 | |
| Maximum input current | A | 28.0 | 11.0 | 17.0 | |
| High pressure value cut-off pressure | MPa | 3.1 | 3.1 | 3.1 | |
| Low pressure valve cut-off pressure | MPa | 0.02 | 0.02 | 0.02 | |
| Brand/Type of Compressor | / | GMCC/Rotary | GMCC/Rotary | GMCC/Rotary | |
| Brand of EEV | Danfoss or Sanhua | Danfoss or Sanhua | Danfoss or Sanhua | ||
| Brand of 4-way valve | Sanhua | Sanhua | Sanhua | ||
| Brand of Pressure sensor | Sanhua or Match-Well | Sanhua or Match-Well | Sanhua or Match-Well | ||
| Refrigerant | / | R290 | R290 | R290 | |
| Air flow | m3/h | 8000 | 8000 | 9000 | |
| Brand of Water pump | WILO or SHIMGE | WILO or SHIMGE | WILO or SHIMGE | ||
| Waterproof grade | / | IPX4 | IPX4 | IPX4 | |
| Noise pressure ( at 1m/5m) | dB(A) | 56/42 | 56/42 | 58/44 | |
| Max water outlet temperature | °C | 70 | 70 | 70 | |
| Diameter of water connection | / | DN 25 (G1") | DN 25 (1") | DN 32 (G1.5") | |
| Internal pressure drop at rating water flow | kPa | 50 | 50 | 50 | |
| Min/Max outdoor air (heating mode ) | °C | -25/45 | -25/45 | -25/45 | |
| Min/Max outdoor air (cooling mode ) | °C | 15/45 | 15/45 | 15/45 | |
| Net Dimensions ( L/W/H ) | mm | 1106/445/1591 | 1106/445/1591 | 1106/445/1591 | |
| Package Dimensions ( L/W/H ) | mm | 1150/455/1671 | 1150/455/1671 | 1150/455/1671 | |
| Net Weight | kg | 168 | 108 | 168 | |
| Gross Weight | kg | 183 | 118 | 183 | |
| Loading quantity 20GP/40GP,40HQ | pcs | 24/52/52 | 24/52/52 | 24/52/52 | |
Q: How long for your heat pump delivery time?
A:Generally it is 1-5 working days if the goods are in stock. or it is 15-25 working days if the goods are not in stock, it is
according to quantity.
Q: Are you heat pump supplier of trading company or manufacturer ?
A: We are R&D and manufacturer factory. with OEM /ODM service provided.
Q: What is your terms of payment for heat pump ?
A: T/T ,balance before shipment. AIibaba trade assurance payment available.
