Rated volume capacity:
60L ,80L,100L,120L,150L,200L,300L
| Product parameters-A Series | |||||
| Optional: with or without WIFI - with or without solar coil | |||||
| Product name | All In One Heat Pump Water Heater | ||||
| Model | BOHW-10-150-C1-A | BOHW-10-150-C1-A | BOHW-10-200-C1-A | BOHW-10-250-C1-A | BOHW-10-300-C1-A |
| Rated volume capacity | 150L | 150L | 200L | 250L | 300L |
| Rated heating capacity | 3250W | 3250W | 3250W | 3250W | 3250W |
| Rated temperature | 75℃ | 75℃ | 75℃ | 75℃ | 75℃ |
| Max. temp. by heat pump | 75℃ | 75℃ | 75℃ | 75℃ | 75℃ |
| Max. temp. by E-heater | 75℃ | 75℃ | 75℃ | 75℃ | 75℃ |
| Rated power input by heat pump | 755W | 755W | 755W | 755W | 755W |
| Rated power input by E-heater | 1500W | 1500W | 1500W | 1500W | 1500W |
| Maximum power input | 2255W | 2255W | 2255W | 2255W | 2255W |
| Rated power supply | 220-240V/50Hz | ||||
| COP | 4.0 | 4.0 | 4.0 | 4.0 | 4.0 |
| Compressor model | RDSM170V11TKZ | ||||
| Control Method | Wired Remote Controller | ||||
| Refrigerant | R290 | ||||
| Cold Water Inlet | 3/4-M(Can be customized) | ||||
| Hot Water Oulet | 3/4-M(Can be customized) | ||||
| Drain port | 1/2-M | ||||
| Mg Anode | Rp 3/4（Φ22*300MM） | ||||
| PT valve port | Rp 3/4 | ||||
| PT valve | 3/4-0.7Mpa-90℃ | ||||
| Tank rated pressure | 0.6Mpa | ||||
| Inner tank material | SUS304 | ||||
| Condenser | Micro-Channel Heat Exchanger | ||||
| Outer material | Painted galvanized steel or stainless steel | ||||
| Insulation | polyurethane foam | ||||
| Insulation thickness | 50MM | ||||
| Noise dB(A) | 53 | ||||
| Sound pressure at 1 M （dB） | 38 | ||||
| Net weight | 52Kg | 52Kg | 60Kg | 66Kg | 75Kg |
| Net size | Φ520*1615MM | Φ560*1345MM | Φ560*1615MM | Φ560*1935MM | Φ650*1705MM |
| Package weight | 57Kg | 57Kg | 70Kg | 76Kg | 87Kg |
| Package size | 590*590*1715MM | 590*590*1445MM | 625*625*1715MM | 625*625*2035MM | 690*690*1805MM |
Green environmental protection
The product adopts natural energy, no exhaust gas ditching, no smoke emission, no toxic gas emission, keep clean environment.
High efficiency and energy saving
he product consumes less electricity, absorbs and utilizes a large amount of heat energy in the air, with low running cost, saving a lot of electricity.
Safe and reliable
Products through the medium of heat exchange, no electric heating elements and water contact, clean water, no fuel, no flammable and explosive poisoning phenomenon.
Easy to install
Products can be installed indoors and outdoors, balconies, etc., without the need for professional equipment room, convenient and simple installation, can achieve multi-point simultaneous water supply.
Q：What kind of material do you use?
A：For inner tank it can be SUS304, SUS316L and Duplex2205. For the outer case, it can be galvanize steel with painting, SUS201 and SUS304.
Q: What is the water tank volume?
A: We can provide 30L 40L 60L 80L 100L 120L 150L 200L 260L 300L 400L 500L 600L 800L 1000L and any other volume for client.
Q: What payment method do you accept for all in one heat pump?
A: T/T(Bank transfer), Alipay, etc.
